Elevon Servo Control
The possible servo reversing options for a delta wing model are:
Aileron
Normal
Normal
Reverse
Reverse
TIP: If you test all servo reversing options and the control
surfaces do not move in the correct direction, change the
Elevon wing type in the System Setup list from Elevon A to
Elevon B.
IMPORTANT: If you are using a stabilized receiver, refer to the
instructions included with your receiver or BNF aircraft.
IMPORTANT: The flap menu is enabled with an elevon mix, it is
intended to be used for drag brakes.
Differential (Function List)
If you enable a wing type with two aileron servos, the function
menu will have a Differential menu added. This feature is intended
for you to be able to set the ailerons for equal travel, or to be able
to set them for more up travel than down travel, depending on your
aircraft and intentions.
To use the differential system:
1. Select the switch you want to use. If you want to use one
setting full-time, set the Switch to ON.
2. Set your values to achieve your desired results. Positive and
negative values will have an opposite effect.
V-Tail Differential (Function List)
If you enable a V-Tail tail type, the function menu will have a
V-Tail Differential menu added. This feature is intended for you
to be able to set the control surfaces for equal travel, or to be able
to set them for more up travel than down travel, depending on your
aircraft and intentions.
To use the v-tail differential system:
1. Select the switch you want to use. If you want to use one
setting full-time, set the Switch to ON.
2. Set your values to achieve your desired results. Positive and
negative values will have an opposite effect.
SPEKTRUM NX10 + • TRANSMITTER INSTRUCTION MANUAL
www.modellmarkt24.ch
Elevator
Reverse
Normal
Reverse
Normal
Left
Rudder
Right
Rudder
Up
Elevator
Down
Elevator
Left
Aileron
Right
Aileron
