Spectrum NX10+ Bedienungsanleitung Seite 27

Battery Alarm
The Battery Alarm is set to LiIon battery type for the NX10+ and
cannot be changed. The alarm activates when the battery reaches
the low voltage limit.
To change the battery voltage trigger point for the alarm:
1. Scroll to the battery voltage and press the scroll wheel.
2. Turn the scroll wheel left or right to change the voltage level.
3. Press the scroll wheel again to save the selection.
Selecting a Language
In the Systems Settings screen, scroll to highlight language, then
press the scroll wheel to select the language function. Scroll
to select the desired Language. When the desired Language is
selected, press the scroll wheel to accept that Language. Names
you input will not be affected by language change. After changing
the language for the text, you may also want to change the
language for the spoken alerts.
Inactive Alarm
An alarm activates if the transmitter sees a period of inactivity for
a certain amount of time. The alarm is helpful in reminding you
to power off the transmitter and avoiding a situation where the
transmitter battery completely discharges.
The Inactive Alarm options are:
• Inh (No alarm • 5 min
sounds) • 10 min (Default)
Set Date/Time
When you select this option another screen is opened. Set the time
and choose the options to suit your needs.
IMPORTANT: Set your Timezone Offset (time zone) first, then your
Daylight Savings mode, then your 12/24 mode. After that, entering
the date and time will show correctly.
Factory Reset
Select this option to reset the NX10+ back to factory settings.
Choosing this option will reset any settings and all models that
have been set in the NX10+ programming, as well as any WiFi
and My Spektrum account information from the transmitter. It does
not change your firmware back to the factory version, nor does it
affect the Stick Mode as this is a mechanical setting as well as a
configuration setting.
Calibrate
Select NEXT at the bottom of the System Settings page to
access the Calibration page. The Calibration screen stores
the potentiometer endpoints for all proportional controls. It is
mandatory to complete the calibration after changing the stick
mode selection.
To Calibrate the Transmitter:
1. Carefully move the gimbal sticks in a + shape moving from
left to right, then up and down. Press gently on the gimbals
at the stops to achieve an accurate calibration. Return both
gimbal sticks to the center position.
2. Select SAVE to store the calibration.
SPEKTRUM NX10 + • TRANSMITTER INSTRUCTION MANUAL
www.modellmarkt24.ch
To change the Inactive alarm time:
1. Scroll to the current alarm time and press the scroll wheel.
2. Scroll left or right to change the alarm time. Press the scroll
wheel to save the selection.
• 30 min
• 60 min
EN
27
