IN STAL L ATION P RE PAR AT IO N
76 cm
• To avoid personal injury and injury, ensure that the fan is hung in a location that allows the
blades to be 2.3 m or more from the floor and 76 cm from the nearest wall or obstacle.
• Make sure the mounting bracket is properly attached to the building structure and can
support the full weight of the fan.
FIX I NG TH E MOU NTI NG B R ACKE T
• Check that the ceiling where you intend to mount the fan is stable and capable of safely
supporting the weight of the fan.
• Do not fix the mounting bracket directly on ceilings less than 10mm to avoid the risk of the
screw loosening and coming out.
• Mark the correct position of the holes and fix the mounting bracket using the screws with
metal anchors or screws and washers suitable for the type of ceiling chosen.
Wood roof
Drill the necessary holes
and then secure the mount-
ing bracket with the wood
screws and washers to the
ceiling joints.
* The waterproof cover is only required for outdoor use.
• Once the fixing bracket is installed, check its correct installation before hanging the fan.
The mounting bracket must support the entire weight of the fan.
E NGL I SH
10
INSTALLATION INSTRUCTIONS
76 cm
2.3 m
*
Concrete roof
Drill holes with an 8mm drill
bit, according to the length
of the expansion screws.
Next, secure the mounting
bracket to the ceiling with
the expansion screws.
76 cm
*
Drill the necessary holes and
then fix the mounting brac-
ket with the special spring
lever fixing screws for use in
false ceilings.
76 cm
2.3 m
*
False ceiling
