EN
Electronic board connections
AUX 1
AUX 2
pH PUMP
AUX 2
AUX 1
Cl
pH-
pump
pump
3 X Output 230 Vac
Main screen and functions
1
2
4
3
pH
7.25
7.60
123
ClmV
725
750
27.2
FLOW
°C
12:15
OK
Elite
Connect
1) Wi-Fi status LED
7) pH
2) Statistics menu
8) ORP / Clppm
3) Confi guration menu
9) Sensors (temperature /
4) Information menu
salinity)
5) Relay menu
10) Bluetooth connectivity
6) Alarm LED
11) Home menu
12) Relay status
See complete manual for further
information on:
• pH and ClmV/Clppm menu
• Relay menu (R1-R4)
Initial Start-Up
1. Make sure that the fi lter is clean and that there is no copper or iron in the water in the pool
or the installation.
2. Balance the pool water. This will enable more effi cient treatment with a lower concentra-
tion of free chlorine in the water and reduce the build-up of limescale in the pool.
3. If the pool is to be used immediately, chlorine treatment should be carried out. Initial dose:
2 mg/L trichloroisocyanuric acid.
4. Before starting the operating cycle, disconnect the control unit and run the fi lter pump for
24 hours to ensure complete dissolution of the salt.
5. Start the saline electrolysis system, setting production at a value between the recom-
mended levels of free chlorine (0.5–2 ppm).
See complete manual for further information on:
• Installation and calibration of pH, ORP, ppm and temperature sensors
• Maintenance of peristaltic pumps
AUX 1
AUX 2
-
-
+
+
<3V
>3V
5
pH set point
6
pH
Clppm Sens
7
7.60
pH
7.25
7.60
123
8
ClmV
725
9
750
27.2
FLOW
°C
12:15
OK
10
11
12
TREATMENT AND PUMP CONTROL
PUMP AND TREATMENT
SYSTEM PROGRAM-CON-
TROLLED
Blue
PUMP AND TREATMENT
SYSTEM ON
Green
PUMP AND TREATMENT
SYSTEM OFF
Red
Disinfection
treatment, Cl2 &
pH sensors
HEAT
4 X OUTPUT FREE POTENTIAL
OUTPUT
FREE
(Loop max 24V 1A AC-DC)
POTENTIAL
Use of Relay Box recommended (SKU:72454)
pH
7.25
7.60
123
ClmV
725
750
27.2
FLOW
°C
12:15
OK
R1
R2
R3
R4
EXTERNAL DEVICES CONTROL
pH
7.25
7.60
123
ClmV
725
750
27.2
FLOW
°C
12:15
OK
The water must be maintained within the follow-
ing parameters:
• Total alkalinity between 60 and 120 mg/L (ppm)
• pH between 7.2 and 7.6
• Free chlorine between 0.5 and 2 mg/L (ppm)
• Chlorine stabiliser between 25 and 30 mg/L
(ppm). In pools that are exposed to strong sun-
shine or intensively used, it is advisable to main-
tain a level of 25–30 mg/L of stabiliser (isocya-
nuric acid).
Check and maintain correct water balance
throughout the season.
4 X INPUT FREE POTENTIAL
(Loop 0V)
INTERLOCKS
Choose language
/Confi g
pH
7.25
Screen
100
7.60
Language
ENG
123
Sound
ClmV
725
Touch
750
27.2
FLOW
°C
12:15
OK
Cl set point
pH
Clppm Sens
720
pH
7.25
7.60
123
ClmV
725
750
27.2
FLOW
°C
12:15
OK
RELAY PROGRAM-
CONTROLLED
Blue
ON
Green
OFF
Red
Pool water balance
/Confi g
Language ENG
Screen
100
Language
ENG
ENG
Sound
Touch
SAVE
