Lamp
The device is equipped with an illumination of the working area fig. A8.
The lamp switches on when the switch is pressed Fig. A3. When the
pressure on the button is released, the lamp switches off automatically
after a few seconds.
Assembly of the work tool
Note: make sure the tool is switched off before mounting. Remove the
battery pack before assembly. Slide the correct size socket onto the
tool holder Fig. A1 until it audibly engages. Check that the socket is
properly seated by pulling lightly on the socket. Note: Use only sockets
with the correct socket size. Use socket adapter if necessary.
Belt clip assembly
The tool is equipped with a clip that allows the device to be clipped to a
belt. If necessary, the clip can be removed and fitted by
screwing/unscrewing the fixing screw.
MAINTENANCE AND STORAGE
• It is recommended to clean the device immediately after each use.
• Do not use water or other liquids for cleaning.
• Clean the power tool, battery pack and charger with a dry piece of
cloth or blow through with low-pressure compressed air.
• Do not use any cleaning agents or solvents as these may damage
the plastic parts.
• Clean the ventilation slots in the motor housing regularly to prevent
the unit from overheating.
• Always store the power tool in a dry place out of the reach of
children.
• Store the device with the battery removed.
• Note: Any type of fault should be rectified by an authorised
manufacturer's service.
RATING DATA
Cordless impact spanner 58G038
Parameter
Engine type
Battery voltage
No-load speed (1st gear/ 2nd gear/
3rd gear)
Torque tightening (1st gear/ 2nd gear/
3rd gear)
Impact frequency
Tool holder
Max. unscrewing torque
Protection class
Mass
Year of production
58G038 indicates both the type and the machine designation
NOISE AND VIBRATION DATA
Sound pressure level (screwdriver
mode)
Sound
pressure
level
spanner mode)
Sound
power
level
(screwdriver
mode)
Sound power level (impact spanner
mode)
Vibration
acceleration
(screwdriver mode)
Vibration acceleration value (impact
spanner mode)
Information on noise and vibration
The noise emission level of the equipment is described by: the emitted
sound pressure level Lp
and the sound power level Lw
A
denotes measurement uncertainty). Vibration emitted by the equipment
is described by the vibration acceleration value a
measurement uncertainty).
The sound pressure level Lp
vibration acceleration value a
measured in accordance with IEC 62841-1. The vibration level a
can be used for comparison of equipment and for preliminary
assessment of vibration exposure.
The vibration level quoted is only representative of the basic use of the
unit. If the unit is used for other applications or with other work tools,
the vibration level may change. A higher vibration level will be
influenced by insufficient or too infrequent maintenance of the unit. The
reasons given above may result in increased vibration exposure during
the entire working period.
In order to accurately estimate vibration exposure, it is necessary
to take into account periods when the unit is switched off or when
Value
Brushless
18 V DC
0-1600/0-2100/0-2600
-1
min
200/300/420 Nm
2000/2600/3300 min
½'' square
450 Nm
III
1.3 kg
2025
Lp
= 72.86 dB(A) K= 3
A
dB(A)
(impact
Lp
= 98,38 dB(A) K= 3
A
dB(A)
Lw
= 80.86 dB(A) K= 3
A
dB(A)
Lw
= 106.38 dB(A) K=
A
3 dB(A)
2
value
a
= 1.129 m/s
h
2
m/s
2
a
= 33.13 m/s
h
2
m/s
(where K is the
h
, the sound power level Lw
A
given in these instructions were
h
it is switched on but not used for work. Once all factors have been
accurately estimated, the total vibration exposure may turn out to
be much lower.
In order to protect the user from the effects of vibration, additional safety
measures should be implemented, such as cyclical maintenance of the
machine and working tools, securing an adequate hand temperature
and proper work organisation.
ENVIRONMENTAL PROTECTION
"GTX Poland Spółka z ograniczoną odpowiedzialnością" Spółka komandytowa with its
registered office in Warsaw, ul. Pograniczna 2/4 (hereinafter: "GTX Poland ") informs that
all copyrights to the content of this manual (hereinafter: "Manual"), including among
others. All copyrights to the contents of this Manual (hereinafter referred to as "Manual"),
including but not limited to its text, photographs, diagrams, drawings, as well as its
composition, belong exclusively to GTX Poland and are subject to legal protection
pursuant to the Act of February 4, 1994 on Copyright and Related Rights (i.e. Journal of
Laws 2006 No. 90 Item 631 as amended). Copying, processing, publishing, modifying for
commercial purposes the entire Manual as well as its individual elements without the
written consent of GTX Poland is strictly prohibited and may result in civil and criminal
liability.
EC Declaration of Conformity
Manufacturer: GTX Poland Sp. z o.o. Sp.k., 2/4 Pograniczna St. 02-285
Warsaw
Product: Brushless impact spanner
Model: 58G038
Trade name: GRAPHITE
Serial number: 00001 ÷ 99999
This declaration of conformity is issued under the sole responsibility of
the manufacturer.
The product described above complies with the following documents:
Machinery Directive 2006/42/EC
Electromagnetic Compatibility Directive 2014/30/EU
RoHS Directive 2011/65/EU as amended by Directive 2015/863/EU
And meets the requirements of the standards:
EN 62841-1:2015+A11; EN 62841-2-2:2014;
-1
EN IEC 55014-1:2021; EN IEC 55014-2:2021;
EN IEC 63000:2018
This declaration relates only to the machinery as placed on the market
and does not include components
added by the end user or carried out by him/her subsequently.
Name and address of the EU resident person authorised to prepare the
technical dossier:
Signed on behalf of:
GTX Poland Sp. z o.o. Sp.k.
2/4 Pograniczna Street
02-285 Warsaw
Paweł Kowalski
GTX Poland Quality Officer
K= 1.5
Warsaw, 2022-11-16
K= 1.5
(where K
A
ACHTUNG, BEVOR SIE DAS ELEKTROWERKZEUG BENUTZEN,
LESEN SIE DIESES HANDBUCH SORGFÄLTIG DURCH UND
BEWAHREN SIE ES ZUM SPÄTEREN NACHSCHLAGEN AUF.
and the
A
BESONDERE SICHERHEITSBESTIMMUNGEN
Tragen Sie bei der Arbeit mit dem Werkzeug einen Gehörschutz und
given
h
eine Schutzbrille. Lärmbelastung kann zu Gehörschäden führen.
Metallspäne und andere umherfliegende Partikel können zu
dauerhaften Augenschäden führen.
Benutzen Sie das Werkzeug mit den zusätzlichen Griffen, die im Kit
enthalten sind, falls vorhanden. Achten Sie darauf, dass das
Werkzeug während des Betriebs nicht außer Kontrolle gerät.
ZUSÄTZLICHE REGELN FÜR SICHERES ARBEITEN
8
Electrically-powered products should not be disposed of with
household waste, but should be taken to appropriate facilities for
disposal. Contact your product dealer or local authority for information
on disposal. Waste electrical and electronic equipment contains
substances that are not environmentally friendly. Unrecycled
equipment poses a potential risk to the environment and human
health.
DEUTSCH(DE)
ÜBERSETZUNG DER ORIGINALANLEITUNG
Schnurloser Schlagschrauber:
58G038
