CLEANING THE SPRAY ARMS
1. Remove the upper and lower baskets.
2. Remove the nut (A). See figure 26.
3. Remove the upper spray arm (B).
4. Pull the lower spray arm (C) upwards to remove it.
5. Clean the spray arms. Use warm water.
6. Install the lower spray arm (C). See figure 27.
7. Install the upper spray arm (B).
8. Tighten the nut (A).
26
A
B
CLEANING THE PUMP
Due to food residues or foreign objects not collected by the filters, the water pump could get clogged.
In that case, the rinse water level is above the filter. Clean the pump to remove the blockage.
Warning:
Glass fragments or sharp objects could cause injury.
1. Check that the appliance is disconnected.
2. Remove the lower basket.
3. Remove the filters in accordance with the instructions in section Cleaning the filters.
4. Remove the excess water. Use a sponge or cloth for this.
5. Push the cap of the drain pump towards 1. See figure 28.
6. Lift up the cap of the drain pump towards 2.
7. Remove the blockage and check the rotor of the drain pump.
8. Push the cap of the drain pump towards 3 until you hear a click sound. Check that the cap falls into the grooves.
See figure 29.
9. Place the filters.
10. Place the baskets.
28
2
27
A
C
29
B
C
41
