PROTECTING THE ENVIRONMENT
Disposal of old equipment
When to be definitively put out of operation, take the product to a local recycling plant for a
disposal which is not harmful to the environment. Devices marked with this symbol must not be
disposed of as household waste. Contact your retailer or local authorities for more information.
Remove any inserted batteries and dispose of them separately from the product.
You as the end user are required by law (Battery Ordinance) to return all used batteries/
rechargeable batteries. Disposing of them in the household waste is prohibited. You may return
your used batteries free of charge to collection points in your municipality and anywhere where
batteries/rechargeable batteries are sold. By disposing of used devices and batteries correctly,
you contribute to the protection of the environment.
TECHNICAL SPECIFICATIONS
Power supply:
IP classification:
Protection class:
Power connection:
Cable construction:
Cable length:
Power output:
Battery pack type:
Battery pack:
Lamp type:
LED:
Color temperature:
Flash rate:
DMX channels:
DMX input:
DMX output:
Cooling:
Control:
Projection:
Carrier frequency:
Modulation:
DMX fail mode:
Beam angle (1/2 peak):
Beam angle (1/10 peak):
Housing color:
Attachment system:
Display type:
Diameter mounting holes:
Material:
Dimensions:
Weight:
Remote control
Battery:
100-240 V AC, 50/60 Hz
IP65
Protection class I
Mains input via IP T-Con (M) mounting version
Power supply cord with safety plug
Battery/battery pack built-in
3 x 1.0 mm² H05RN-F
1.1 m
IP T-Con (F) mounting version
1 x lithium ion 22.2 V, 2200 mAh, 48.84 Wh
Battery operation up to 9h depending on program used
Recharging time 3h
LED lamp
6 x 8 W SMD 4in1 QCL RGBW (homogenous color mix)
2700K - 8000K adjustable
1 - 20 Hz
3; 4; 5; 6; 10
3-pin XLR (M) mounting version IP
3-pin XLR (F) mounting version IP
Passive convection cooling
Stand-alone; DMX; QuickDMX; IR remote control; master/slave
function
Flicker-free
2.4 GHz
GFSK
Blackout; hold; full on; static; auto
17°
34°
Black
1x panning and tilting mounting bracket for ceiling or wall
installation in most varying angles
LCD display
Ø11mm
Aluminum casting
Length: 51.0 cm
Depth: 16.0 cm
Height: 14.5 cm
5.3 kg
1 x Button cell 3.0 V CR2025 lithium manganese (provided)
