EuroLite AKKU IP BAR-6 Entry Bedienungsanleitung Seite 37

CH 4
Auto program
CH 5
Speed auto program
6-channel mode
Channel
CH 1
CH 2
CH 3
CH 4
CH 5
Master dimmer
CH 6
Internal programs
Strobe effect
10-channel mode
Channel
CH 1
Master dimmer
CH 2
Strobe effect
CH 3
CH 4
CH 5
CH 6
CH 7
Preset colors
120 – 129 Light green
130 – 139 Orange
140 – 149 Straw
150 – 159 Lavender
160 – 169 Light blue
170 – 179 Dark blue
180 – 189 Pink
190 – 255 All on
000 – 009 No function
010 – 029 Auto program 1
030 – 049 Auto program 2
050 – 069 Auto program 3
070 – 089 Auto program 4
090 – 109 Auto program 5
110 – 129 Auto program 6
130 – 149 Auto program 7
150 – 169 Auto program 8
170 – 255 Auto program 9
000 – 255 Speed auto program, increasing
Value Function
000 – 255 Red, increasing intensity 0 – 100%
000 – 255 Green, increasing intensity 0 – 100%
000 – 255 Blue, increasing intensity 0 – 100%
000 – 255 White, increasing intensity 0 – 100%
000 – 255 Total brightness 0-100 %
000 – 000 No function
001 – 005 Auto control (7 colors)
006 – 010 No function
011 – 255 Strobe with increasing speed 0-100%
Value Function
000 – 255 Total brightness 0-100 %
000 – 009 No function
010 – 255 Strobe with increasing speed 0-100%
000 – 255 Red, increasing intensity 0 – 100%
000 – 255 Green, increasing intensity 0 – 100%
000 – 255 Blue, increasing intensity 0 – 100%
000 – 255 White, increasing intensity 0 – 100%
000 – 009 No function
010 – 019 Red
020 – 029 Green
030 – 039 Blue
040 – 049 White
050 – 059 Yellow
060 – 069 Magenta
070 – 079 Cyan
37/40
00156821, Version 1.1
