OPERATION
Turn on the device via the power button. The display indicates the last operating mode. The operating
modes can be selected by means of the display and the control buttons. All settings remain stored even if
the device is disconnected from the mains. The device can be operated in stand-alone mode via the control
board and the EUROLITE IR-7 remote control or in DMX-controlled mode via any commercial DMX
controller.
Operating buttons
Button
MENU
ENTER
UP
DOWN
Menu structure
Mode
DMX mode
Preset colors
Automatic mode
Running speed in
automatic mode
Color mix
Color temperature
Dimmer
Fading
Strobe effect
Behaviour in case of
missing DMX signal
Slave mode
AKKU mode
Function
Selects the operating mode or returns to the initial screen.
Activates a value to be modified or saves a value when modifying.
Selects the next menu item or increases values when modifying.
Selects the previous menu item or decreases values when modifying.
Display
10CH
06CH
DMX 05CH
04CH
03CH
STATIC
AUTO
SPEED
COLOR
TEMPERAT
DIMMING
FADING
FLASH
DMX lost
SLAVE SLAVE MODE
BATTERY
ADDR:001-512 10-channel mode and start address
ADDR:001-512 6-channel mode and start address
ADDR:001-512 5-channel mode and start address
ADDR:001-512 4-channel mode and start address
ADDR:001-512 3-channel mode and start address
01-19 Constant lighting in one of 19 colors
01-09 Auto Program
Program running speed
01-09
slow > fast
R000-255 Red 0-100%
G000-255 Green 0-100%
B000-255 Blue 0-100%
W000-255 White 0-100%
2700K 2700K
3200K 3200K
4300K 4300K
5600K 5600K
6500K 6500K
8000K 8000K
01-99 Total brightness, dark > bright
00-99 Fading program, slow > fast
00-99 Strobe effect, slow > fast
Blackout LEDs go off
Hold Spot holds the last received signal
Full All LEDs 100% on
Static Pre-selected static color 01-19
Auto Pre-selected auto program 01-09
Slave mode
Super Super bright mode
Normal Normal mode
Economy Energy saving mode
32/40
