EuroLite AKKU IP BAR-6 Entry Bedienungsanleitung Seite 33

Key lock
Wireless 2.4 G
IR remote control
Firmware version
Stand-alone mode
Preset colors
In the STATIC mode the device will constantly emit one of 19 preset colors.
1 Press the MENU button until STATIC is indicated in the display. Confirm with the ENTER button.
2 Use the buttons UP and DOWN to adjust the desired color. Confirm with the ENTER button.
Automatic mode
In automatic mode, 9 show programs are available that run at an adjustable speed.
1 Press the MENU button until AUTO is indicated in the display. Confirm with the ENTER button. Use the
buttons UP and DOWN to select the desired show program (01 – 09). Confirm with the ENTER button.
2 Press the MENU button so many times until SPEED is indicated in the display. Confirm with the ENTER
button. Use the buttons UP and DOWN to adjust the running speed of the program from 01 (slow) to 09
(fast). Confirm with the ENTER button.
Color mix
In COLOR mode the 4in1 LEDs can be adjusted in intensity. The device will then constantly emit the chosen
color setting.
1 Press the MENU until COLOR is indicated in the display. Confirm with the ENTER button.
2 Now the display indicates the letter R for the color red and the corresponding brightness value. Use the
buttons UP and DOWN to adjust the desired brightness.
3 Confirm with the ENTER button. Now the color green can be set; then blue and white until the desired
color intensity is achieved.
Color temperature
In TEMPERAT mode, the device emits a constants white light. The color temperature of the device is
adjustable.
1 Press the MENU until TEMPERAT is indicated in the display. Confirm with the ENTER button.
2 Use the buttons UP and DOWN to adjust the desired color temperature (2700K - 8000K).
Total brightness
Menu item DIMMING allows adjusting the total brightness for all stand-alone operating modes.
1 Press the MENU button until DIMMING is indicated in the display. Confirm with the ENTER button.
2 Use the buttons UP and DOWN to adjust the desired brightness (01 = dark, 99 = bright). Confirm with
the ENTER button.
Color fading
FADING mode enables color fading. The speed is adjustable.
1 Press the MENU button until FADING is indicated in the display. Confirm with the ENTER button.
2 Use the buttons UP and DOWN to adjust the desired speed (00-99). Confirm with the ENTER button.
PASSCODE
SET 2.4 G
ON/OFF
INFRARED
V1.0
ON Key lock on
OFF Key lock off
Red
Green
Blue
Transmission channel wireless
R+G DMX
G+B
R+B
ON IR remote control on
OFF IR remote control off
Vxxx Firmware version number
33/40
00156821, Version 1.1
