1. Description of function

CDP 35, 45 and 65 are working in accordance with the condensation principle. The humid air is drawn into the unit
by one, two or three fans. When passing through the evaporator the air is cooled down to below dew point and
water vapour is condensed into water, which is drained away. The now dry air is then passed over the condenser
coil where the air is heated. As a result of the released evaporator heat and the working energy of the compressor
being turned into heat energy, more heat is returned to the air than was previously extracted. This extra heat
corresponds to an approximate increase in temperature of 5ºC. The repeated circulation of air through the unit
reduces the relative humidity, giving very rapid but gentle drying.

1.1 Technical data

Working area – humidity
Working area – temperature
Air volume at max. external pressure
Power supply
Max. power consumption
Max. ampere consumption
Refrigerant
Quantity of refrigerant
Sound level (1 m away from unit)
Weight
Dimensions – H x L x W
Warm, humid air
%RH
ºC
3
m /h
V/Hz
kW
A
kg
dB(A)
kg
mm 800 x 950 x 315 800 x 1260 x 315 800 x 1800 x 315
9
Warmer and dehumidified air
CDP 35 CDP 45
40-100 40-100
10-36 10-36
250 500
1x230/50 1x230/50
0,72 1,05
2,8 4,3
R407C R407C
0,6 0,95
47 49
60 74
CDP 65
40-100
10-36
750
1x230/50
1,65
7,2
R407C
1,6
51
101
