EnGLIsh
THE BLADE OR OTHER PARTS OF THE BLADE SYSTEM CAN CAUSE
SERIOUS INJURY.
WARNING: Use gloves and proper eye protection. Be careful
of the sharp edges on the blade.
Replacement blades are available from your nearest
authorized service center. This pruner requires replacement
blade SFMCPPRB1.
1. Remove the battery.
2. Wear proper eye protection and gloves and be careful not to
cut yourself.
3. Place the product on a smooth, level surface.
4. Using the blade lock knob
screw
and nut
as shown in Fig. M.
23
24
5. Remove the cutting blade
6. Install the new cutting blade.
nOTE: Ensure the cutting edge faces toward the fixed cutting
blade as shown in Fig. M.
7. Insert the cutting blade screw
and into the nut
24
.
8. Use the blade lock knob
blade screw
23
.
Blade Maintenance (Fig. N)
WARNING: Use gloves and proper eye protection while
removing, sharpening, and installing blade.
The cutting blades are made from high quality, hardened steel
and with normal usage, they will not require resharpening.
However, if you accidentally hit a wire fence, stones, glass, or
other hard objects, you may put a nick in the blade. There is no
need to remove this nick as long as it does not interfere with the
movement of the blade. If you drop the trimmer, carefully inspect
it for damage. If the blade is bent, housing cracked, handles
broken or if you see any other condition that may affect the tool's
operation contact your local authorized service center for repairs
before putting it back into use.
1. Remove the battery.
2. Remove blade from pruner. See instructions for Removing
and Installing Blade.
3. Wear proper eye protection and gloves and be careful not to
cut yourself.
4. Secure blade
in a vise
8
5. Carefully file the cutting edge
a fine tooth file
27
(not included) or sharpening stone (not
included), maintaining the angle of the original cutting edge of
the cutting blade.
6. Inspect the edge of the fixed blade and remove any burrs
with a fine tooth file.
7. Install sharpened cutting blade as described in the
Removing and Installing Blade section.
Blade Lubrication (Fig. A)
1. After use, remove the battery
2. Carefully apply a resin solvent to the exposed blades.
Storage (Fig. A)
1. After use, remove the battery.
2. Keeping your hands away from the blade, and store in a dry
location, away from the reach of children.
32
11
remove the cutting blade
8
as shown in Fig. M.
23
through the cutting blade
11
to fully tighten the cutting
as shown in Fig. N.
25
26
of the cutting blade with
16
.
Lubrication
Your power tool requires no additional lubrication.
Cleaning
WARNING: Electrical shock and mechanical hazard. Remove
the battery before cleaning.
WARNING: To ensure safe and efficient operation, always
keep the electrical appliance and the ventilation slots clean.
WARNING: Never use solvents or other harsh chemicals for
cleaning the non-metallic parts of the tool. These chemicals may
weaken the materials used in these parts. Use a cloth dampened
only with water and mild soap. Never let any liquid get inside the
tool; never immerse any part of the tool into a liquid.
Ventilation slots can be cleaned using a dry, soft non‑metallic
brush and/or a suitable vacuum cleaner. Do not use water or
any cleaning solutions. Wear approved eye protection and an
approved dust mask.
Optional Accessories
WARNING: Since accessories, other than those offered by
STANLEY FATMAX, have not been tested with this product, use of
such accessories with this tool could be hazardous. To reduce the
risk of injury, only STANLEY FATMAX-recommended accessories
should be used with this product.
Consult your dealer for further information on the
appropriate accessories.
STANLEY Track Wall (Fig. O)
WARNING: To reduce the risk of serious personal injury,
turn unit off and remove the battery pack before making
any adjustments or removing/installing attachments or
accessories. An accidental start-up can cause injury.
WARNING: To reduce the risk of serious personal injury, do
not use a damaged STANLEY Track Wall hang hook or STANLEY
Track Wall. A damaged STANLEY Track Wall hang hook or
STANLEY Track Wall will not support the weight of the tool.
WARNING: To reduce the risk of serious personal injury, DO
NOT suspend tool overhead or suspend objects from the hang
hook. ONLY suspend tool on the STANLEY Track Wall using the
hang hook.
WARNING: Ensure that the tool weight does not exceed the
maximum rated weight of 9 kg for the selected STANLEY Track
Wall hook.
WARNING: When hanging objects on a STANLEY Track Wall
rail, adequately space the tools in order to not exceed 35 kg per
linear foot.
IMPORTanT: STANLEY Track Wall accessories mount
compatible tools securely to the STANLEY Track Wall system.
1. Turn the tool off, remove the battery pack and accessories.
CAUTION: Any product with exposed cutting teeth must have
them covered securely if it is to be on the STANLEY Track Wall.
2. Flip or pull open the integral STANLEY Track Wall hang
hook
15
. It clicks when locked into position.
3. Mount the integral hang hook to the STANLEY Track Wall.
nOTE: STANLEY Track Wall accessories for use with your tool
are available at extra cost from your local dealer or authorised
service centre.
