IN STALL AT ION PRE PAR AT I O N
• To avoid personal injury and/or
damage, ensure that the location
where the fan is to be hung allows
the blades to be at least 2.3 m from
the floor and 76 cm from the nearest
wall or other obstacle.
• Ensure that the mounting bracket
is properly secured to the ceiling
and is capable of supporting the full
weight of the fan.
IN STALLI N G THE MOU NT I NG B R ACKE T
• Check that the ceiling where you intend to mount the fan is stable and capable of safely
supporting the weight of the fan.
• Do not fix the mounting bracket directly on ceilings less than 10mm to avoid the risk of the
screw loosening and coming out.
• Mark the correct position of the holes and fix the ceiling bracket using screws with metal
anchors or screws and washers suitable for the chosen ceiling type.
• Once the fixing bracket is installed, check its correct installation before hanging the fan.
The mounting bracket must support the full weight of the fan.
E NGL I SH
10

INSTALLATION INSTRUCTIONS

min. 76 cm
Drill the necessary holes and then secure the mounting
bracket with the wood screws and washers to the ceiling
joints.
Drill holes with an 8mm drill bit, according to the length of
the expansion screws. Next, secure the mounting bracket to
the ceiling with the expansion screws.
Drill the necessary holes and then fix the mounting bracket
with the special spring lever fixing screws for use in false
ceilings.
Wood roof
Concrete roof
False ceiling
min. 76 cm
min. 2.3 m
