Accessing a target module
How to access a target module via on-screen display:
1. Press the
Ctrl+Num
2. Use the
arrow keys
3. Press Enter .
Disconnecting the target module
The Disconnect function disconnects the active connection to the target module. After
this function is carried out, the Select menu is displayed.
How to disconnect a target module:
1. Press the Ctrl+Num
2. Press to open the Operation menu.
F9
3. Press or select
D D - Disconnect
ADVICE:
After you open the on-screen display, you can use the Select menu to
carry out the Disconnect function by pressing
User logout at the KVM matrix system
Use the User logout function to log out of the KVM matrix system. If the logout was
successful, the Login window opens.
IMPORTANT: Always use the User logout function of the matrix system to protect
the user module and the KVM matrix system against unauthorised access.
How to log out of the KVM matrix system:
1. Press the
Ctrl+Num
2. Press F9 to open the Operation menu.
3. Press E or select E - User logout
ADVICE: After you open the on-screen display, you can use the Select menu to
carry out the User logout function by pressing
(default) hotkey to open the on-screen display.
to select the target module to be accessed.
(default) hotkey to open the on-screen display.
and press
(default) hotkey to open the on-screen display.
and press Enter
.
Enter
.
Ctrl+D
.
Ctrl+E .
