Netmask:
Connection type:
7. Press F2 to save your settings.
Configuring «global» network settings
In complex networks, global network settings ensure that the matrix switch is avail-
able from all sub networks.
How to configure global network settings:
1. Press (default) to open the on-screen display of the KVM matrix system.
Ctrl+Num
2. Press to open the Configuration menu.
F11
3. Select Network and press
4. Select Interfaces and press
5. Enter the following data under
Global prefer- Select the operating mode by pressing
ences
 Static:
 DHCP:
DHCP server.
Hostname:
Enter the matrix switch hostname.
Domain: Enter the domain the matrix switch is to belong to.
Gateway:
Enter the gateway IP address.
DNS Server 1: Enter the DNS server IP address.
DNS Server 2:
Enter the IP address of another DNS server (option).
6. Press F2 to save your settings.
Enter the network netmask.
This setting is auto obtained in the DHCP operating mode.
Press F8 to define if the network port and its communication
partner are to negotiate the connection type automatically
( ) or select one of the listed types.
Auto
Enter .
Enter .
Main Network
uses static settings.
auto obtains the settings described below from a
Initial configuration of network settings
:
:
F8
G&D ControlCenter-Digital-288 · 7
