Technical data
13 Technical data
Device short description:
Bus connection supply voltage:
Load voltage:
Bus connection supply current
(stand-by):
Bus connection supply current (max.):
Load current (max.):
Power consumption (stand-by):
Power consumption (max.):
Max. switching capacity:
Relay:
Cable type and cross-section for
connection of loads:
Cable type and cross-section for bus
connection:
Degree of protection:
Ambient temperature:
Dimensions (W x H x D):
Weight:
Load type
Resistive load
Incandescent lamp load
Self-ballasted lamps (LED/
compact fluorescent tube)
HV halogen lamps
Electronic transformers for
LV halogen lamps
Iron core transformers for LV halogen lamps
Fluorescent lamps (uncompensated)
Fluorescent lamps (parallel compensated)
Subject to modifications.
HmIPW-SMO230, HmIPW-SMO230-A
24 V DC, +5% -20%, SELV
230 V/50 Hz
2 mA
40 mA
5 A
0.048 W
0.96 W
1,150 W
NO contact, 1-pole, μ contact, bistable
Rigid and flexible cable,
0.75 – 2.50 mm²
Rigid cable, 0.12 – 0.50 mm²
IP44
-20 to +55°C
78 x 126 x 140 mm
311 g
Relay
5 A
1,150 W
200 W
1,150 W
1,150 W
1,150 W
1,150 W
1,150 W
33
