manually (see the paragraph "VOC sensor calibration -
manual").
During calibration, which lasts 5 minutes, keys T1 - T2 - T3
- T5 - T6 will flash except for key T4. Please note! During
calibration, only the lights key can be used.
T1
T2
T3
T1 = ON (Speed 1) - OFF (motor) key
T2 = ON (Speed 2) - OFF (motor) key
T3 = ON (Speed 3) - Intensive - OFF (motor)
Intensive: it lasts 5 minutes, after which it goes back to the
previously selected setting. It is possible to exit this mode
by pressing any button.
T4= Light ON/OFF and light intensity adjustment
(Dimmer).
- Light intensity adjustment (Dimmer): with the light on, if
you press T4 for more than 2 seconds, an acoustic signal
followed by the flashing of the LED will allow you to adjust
the intensity of the light evenly and calibrated to the work
surface.
T5 = Activates or deactivates the Bluetooth and VOC
sensor function.
- Bluetooth function: activated only with a hob compatible
with the hood. For pairing, see the "Assembly and Use"
manual of the Hob.
- VOC (h24) sensor function: this Product is equipped with
a sensor that modulates the extraction speed automatically
according to the amount of smoke detected.
The function is activated automatically at the end of
calibration (see the Chapter VOC h24 sensor calibration).
T6 = Wi-Fi connectivity key.
- Delayed switch-off of the hood (Delay switch off):
Attention! This function is available only if the product is
NOT connected to the Elica Cloud.
It is possible to set the delayed switch-off of the hood
(OFF) by pressing once again the key of the extraction
speed (power), active at that time with the LED flashing
slowly, for more than 2 seconds, after which the hood
switches off.
The available delayed switch-off times are:
T1= Extraction speed (power) 20 minutes
T2= Extraction speed (power) 15 minutes
T3= Extraction speed (power) 10 minutes.
Please note!
- Briefly pressing the key set to delay switch off switches
off the hood.
- Briefly pressing any key other than the key set to delay
switch off, activates the set extraction speed.
- By long-pressing the key set to delay switch off, the
T4
T5
T6
hood maintains the speed but without timing.
Note: (only for products with Wi-Fi function): the delay
switch off can be programmed in a more advanced way,
when connected to the Elica Cloud, via the Elica Connect
App.
- VOC (h24) sensor calibration
During calibration, which lasts 5 minutes, keys T1-T2-T3-
T5-T6 start flashing; calibration is complete when LEDs T1-
T2-T3-T5 remain lit and are followed by an acoustic signal
(beep) and key T6 indicates the Wi-Fi status.
When the function is active, the LEDs of keys T1-T2-T3- T5
are soft.
During calibration, it is only possible to switch the lights on
and off.
Once activated, if the sensor detects no smoke for a few
minutes, the motor will be switched off.
Note: The Function will still remain active for h24 and if the
sensor detects some steam, the motor will be restarted
automatically.
- To deactivate the VOC (h24) function, briefly press key
T5.
Calibration is necessary to allow the product sensor to
work correctly; calibration is performed in two ways:
Automatic: each time the hood is reconnected to the
mains (e.g. the first time it is installed or after a power
failure).
Manual: Manual calibration requires that the product motor
is OFF and that normal environmental conditions persist in
the room where it is installed. This operation must be
performed when automatic operation is unsatisfactory.
Manual calibration is activated by pressing and holding key
T1+T5 for 6sec.
Hob selection
To use the VOC (h24) function in the best way possible, it
is necessary to select the correct type of hob from those
available: GAS - Induction or Electric. By Default, the hob
is set to Induction.
With the hood and the VOC sensor switched off,
simultaneously press keys T5 and T6 until you hear an
acoustic signal (beep); release the keys and LEDs T1-T2
and T3 will light up with different intensities from bright to
soft and you will enter the hob selection menu.
You can choose the desired hob by briefly pressing the key
according to the following diagram:
T1 - Led 1 lit with high intensity: induction hob
T2 - Led 2 lit with high intensity: gas hob
T3 - Led 3 lit with high intensity: electric hob
To confirm the hob selection, press keys T5 and T6 again
for 6 seconds.
Note: after resetting the hob type, to a type other than the
Default one or the previous one, an automatic calibration of
the VOC (h24) sensor will start.
11
