holes with a diameter equivalent to the air outlet
(connecting flange).
The use of pipes and outlet holes in the wall with a smaller
diameter will reduce the extraction performance and
drastically increase the noise level.
All responsibility in this regard is therefore denied.
• Use a ducting pipe with the shortest length necessary.
• Use a ducting pipe with the least number of bends
possible (maximum bend angle: 90°).
• Avoid drastic changes in the ducting pipe diameter.
●
Recirculating Version:
The suctioned air will be degreased and deodorised before
it is sent back into the room. To use the product in this
version, it is necessary to install an additional activated
carbon filter system.
ASSEMBLY BEFORE INSTALLATION
• Check that the product is the right size for the installation
area.
• Remove the activated carbon filter(s) if supplied (see also
relevant paragraph).
• It(they) must be reinstalled if the product is used in the
filter version.
• If there are panels and/or walls and/or wall units on the
sides, make sure that there is enough space to install the
product and that it is always possible to access the control
panel easily.
• The product is equipped with fixing plugs suitable for most
walls/ceilings. However, it is necessary to consult a
qualified technician to make sure that the materials are
suitable for the type of wall/ceiling. The wall/ceiling must be
strong enough to support the weight of the hood.
LED temperature adjustment
Once the product has been installed, before refitting the
grease filter and the perimeter suction panel, it is possible
to adjust the temperature of the LED, from warm light to
cool light, in order to match it with the light in your room.
The available temperatures are:
W = 3000K warm
N = 3500K medium warm
C = 4000K cool.
ELICA CONNECT
The hood features a Wi-Fi function for remote connection
via the Elica Connect App. Minimum system requirements:
• 2.4GHz Wi-Fi b/g/n wireless router • Android or iOs
Smartphone. Via the stores, check that the app is
compatible with the operating system your Smartphone is
running.
Note: The ELICA manufacturer declares that this model of
household appliance with WiFi module radio equipment
complies with Directive 2014/53/EU.
The radio equipment operates within the 2.4GHz ISM
frequency band, the maximum radio frequency power
transmitted does not exceed 20 dBm (e.i.r.p.).
Warnings:
• Data protection: The data that the connected device
detects is collected to allow for all the services of the
connected appliance to be used. Further information on
how the collected data is processed and on the privacy
policy is available at www.elica.com.
• Availability in different countries: The Elica Connect
service is available in specific countries. For further
information,
see
www.elica.com or check for availability from your
Smartphone store by searching for the Elica Connect App.
• Future changes: Elica reserves the right to make any
changes deemed useful to improve the Elica Connect
service. As a result, the descriptions contained in this
manual are not binding and should be treated as purely
indicative.
ELICA BLUETOOTH
The hood features the Bluetooth function.
It is an automatic function that connects the hob to a hood.
Both the hob and the hood have a radio frequency signal
communicator.
With the Bluetooth connection, the hood will adapt its
operation to the cooking parameters of the induction hob.
The smart algorithm used in the devices accurately
monitors the cooking intensity on the hob and, based on
the data detected, selects the power of the hood.
ATTENTION! For further information on how to use the
function, see the "ASSEMBLY AND USE" manual of the
hob compatible with the hood.
The connection between the Hob and Hood only works
with Elica products. The range of compatible products is
shown on the website www.elica.com.
ATTENTION!
- During the Wi-Fi pairing procedure of the hood with the
Cloud via the Elica Connect App, the Bluetooth
connection services with the hob are temporarily
suspended.
- During the Bluetooth pairing procedure of the hood with
the hob (or when the hob is switched off), the Wi-Fi
connection services with the Cloud via the Elica Connect
App are temporarily suspended.
OPERATION
Please note! This hood features an automatic h24
operation system of the VOC sensor (see the paragraph
"VOC sensor calibration").
Calibration occurs automatically each time the hood is
reconnected to the electrical network (e.g.: the first time it is
installed after a blackout). It can also be performed
10
the
dedicated
section
at
