TECHNICAL SPECIFICATIONS OF DEVICE
Model:
Operating pressure (with neb.):
RESPIRATORY
CONFIGURATION
MMAD (μm)
Output rate (ml/min')
Respirable fraction < 5
μm (FPF)
(1) Data collected according to Flaem's internal procedure.
(2) In vitro characterisation performed by TÜV Rheinland Italia S.r.l. in cooperation with the University of Parma. More
details are available on request.
(3) Data calculated on the basis of the values obtained with the Malvern Spraytec and compared with the values of the
utory tests performed at the University of Parma.
iser;
APPLIED PARTS
ienic
Type BF applied parts are:
Weight:
ENVIRONMENTAL CONDITIONS
Operating conditions:
Ambient temperature
Relative air humidity
Atmospheric pressure
Storage and transport conditions:
Ambient temperature
Relative air humidity
Atmospheric pressure
CONDOR F2000 combined RF9-1
UPPER
AIRWAYS
SYSTEM
Oropharyngeal
tract
Without
Selector
BOWL
5.80
0.75
40.3%
1.30 bar.
Tracheobronchial
tract
Selector in
position 1
(3) 4.67 (2)
(1) 0.54 (1)
54.4%
(3) (2)
patient accessories (B3, B3.2, B4, B5)
2.400 Kg
Between +10°C and +40°C
Between 10% and 95%
Between 69 KPa and 106 KPa
Between -25°C and +70°C
Between 10% and 95%
Between 69 KPa and 106 KPa
9
LOWER AIRWAYS
Pulmonary Peripheral
tract
Selector in Selector in
position 2 position 3
B2.4c B2.4c
3.62 (2)
0.51 (1)
66.3% 82.2%
(2)
tract
2.56 (2)
0.38 (1)
(2)
