Door right-left change (optional)
Based on the location where you plan to use your refrigerator, you may find it more
convenient to reverse the position of the door.
CAUTION
CAUTION: To avoid injury to yourself or your property, we recommend that
someone assist you during the door reversal process.
EN EN
Preparing to reverse the door position
You will need: A standard screwdriver, a Phillips screwdriver, and the included Allen
wrench.
• Make sure that your refrigerator is unplugged and empty.
• Have someone available to assist you in the process.
• Keep all of the parts you remove to reuse them later.
Tools needed for changing the door:
5/16" socket and ratchet
Parts to be used for door reverse
SN Name
1 Shaft sleave
2 Upper hinge screw
3 Right stopper
4 Hinge cover assembly
5 Pillar switch
6 Right hinge cover
7 Right upper hinge
8 Adjustable foot
9 Accessory package
10 Lower hinge assembly
11 Lower hinge screw
12 End cover plate
13 Hole cover
Cross screwdriver
Number
1
1
1
1
1
1
1
1
3
1
2
1
1
Putty knife
thin-blade screwdriver
Masking tape
Notes
Pre-installed on the refrigerator and to be used
when changing the door
Pre-installed on the refrigerator, removed when
the door is reversed, and kept for future use
Pre-installed on the refrigerator and to be used
when changing the door
Pre-installed on the refrigerator, removed when
the door is reversed, and kept for future use
Pre-installed on the refrigerator and to be used
when changing the door
Left upper hinge/Left upper hinge cover/Left
stopper
Pre-installed on the refrigerator and to be used
when changing the door
06
