9.2 Settings
m NOTE
To make adjustments to the product, the robotic lawn-
mower (1) must be switched on. Switch on the robotic
lawnmower (1) by pressing and holding the
("POWER ON/OFF" button) until "PIN" appears on
the display.
9.2.1 Changing the PIN code (Fig. 21)
• Press and hold the "START" and "HOME" buttons
simultaneously for at least 3 seconds.
• The symbol and "PInI" flash.
• Now enter the old PIN code as follows (factory set-
ting "0000").
• The first digit illuminates ("0---").
• Use the "START" and "HOME" buttons to select the
desired digit.
• Confirm the digit with the "OK" button.
• The next digit illuminates (e.g. "10--).
• Proceed as described in paragraph 2-4 above.
• After you have entered the "old" PIN code and con-
firmed the fourth digit with the "OK" button, "PIn2"
appears, now you can enter the new PIN code.
• The first digit flashes ("0---").
• Use the "START" and "HOME" buttons to select the
desired digit.
• Confirm the digit with the "OK" button.
• The next digit flashes (e.g. "10--).
• Proceed as described in paragraph 2-4 above.
• After confirming the fourth digit with the "OK" but-
ton, the new PIN code is stored. The word "IdLE"
appears on the display.
9.2.2 Setting/changing the date/time (Fig. 22)
m NOTE
Date and time are necessary settings so that the ro-
botic lawnmower (1) can mow in accordance with the
set mowing schedule.
• The date/time setting is done in the order year - date
- time.
• Press and hold the "START" button for at least 5
seconds.
• The -symbol and a number (e.g. 2024) flashes
on the display.
• Use the "START", "HOME" and "OK" buttons to set
the year, similarly to the PIN setting.
• Then the next number illuminates (month.day e.g.
08.25 for 25 August).
• Use the "START", "HOME" and "OK" buttons to set
the correct month and day.
• The time is displayed last (e.g. 13:25).
• Set the current time as described above.
• After confirming the fourth digit with the "OK" but-
ton, the date and time are stored. The word "IdLE"
appears on the display.
28 | GB
9.2.3 Changing the start time (Fig. 23)
The factory-set start time of 09:00 can be changed at
any time.
• Press and hold the "START" and "OK" buttons si-
multaneously for at least 3 seconds.
-button • The display shows the set start time, e.g. 13:25, with
the first digit flashing.
• Use the "START" and "HOME" buttons to select the
desired digit and confirm with the "OK" button.
• Proceed as described in paragraph 2-4 above.
• After confirming the fourth digit with the "OK" but-
ton, the new start time is stored. The word "IdLE"
appears on the display.
9.2.4 Changing the mowing time/day (Fig. 24)
The factory-set mowing time per day of 3 hours can
be changed at any time.
• Press and hold the "OK" button for at least 3 seconds.
• The display shows the set mowing time, e.g. 06 H,
with the first digit flashing.
• Use the "START" and "HOME" buttons to select the
desired digit and confirm with the "OK" button.
• After confirming the second digit with the "OK" but-
ton, the new mowing time or the new day is stored.
The word "IdLE" appears on the display.
9.3 Mowing edges
The default setting is for the robotic lawnmower (1) to
mow the edges every Tuesday and Friday.
This means that the robotic lawnmower (1) travels
once along the boundary wire (11) the first time it
mows for the day.
m ATTENTION
In this mode, the blade disc (6) is active.
9.4 Changing the default rain sensor setting
Press and hold the "HOME" button for 3 seconds, then
"Rain" will appear on the display. Press "OK" to access
the settings interface. Then "ON" or "OFF" is displayed.
You can change the settings by pressing the "START"
and "HOME" buttons and confirm with the "OK" button.
9.5 Activating/deactivating mowing zones
The model is equipped with a multi-range function
that allows the robot to operate from two pre-set
starting points: at 0% and 50% of the total length of
the edges to be mowed.
The starting point 0% is at the beginning of the
mowing area, while the starting point at 50% is in
the middle of the edges. This function ensures even
coverage of the mowing area.
1. Press and hold the Home button for 3 seconds
until "Rain" appears on the display.
2. Press the START or HOME button to scroll
through the options until "Zone" is displayed.
