m ATTENTION!
Always make sure the product is fully assembled
before commissioning!
Electrical connection
The electrical motor installed is connected and ready
for operation. The connection complies with the appli-
cable VDE and DIN provisions.
The customer's mains connection as well as the ex-
tension cable used must also comply with these reg-
ulations.
Damaged electrical connection cable
The insulation on electrical connection cables is often
damaged.
This may have the following causes:
• Pressure points, where connection cables are
passed through windows or doors.
• Kinks where the connection cable has been improp-
erly fastened or routed.
• Places where the connection cables have been cut
due to being driven over.
• Insulation damage due to being ripped out of the
wall outlet.
• Cracks due to the insulation ageing.
Such damaged electrical connection cables must not
be used and are life-threatening due to the insulation
damage.
Check the electrical connection cables for damage regu-
larly. Ensure that the connection cables are disconnect-
ed from electrical power when checking for damage.
Electrical connection cables must comply with the ap-
plicable VDE and DIN provisions.
Only use connection cables of the same designation.
The printing of the type designation on the connection
cable is mandatory.
9.1 Quick start (Fig. 19/20)
After installing the boundary wire (11), you can use the
robotic lawnmower (1).
Adjusting the cutting height
• Turn the cutting height adjustment knob (2) clock-
wise to increase the cutting height seamlessly be-
tween 20 - 50 mm.
• Turn the cutting height adjustment knob (2) an-
ti-clockwise to decrease the cutting height seam-
lessly between 20 - 50 mm.
m NOTE
The arrow on the cutting height adjustment knob (2)
points to numbers outside the knob. Here you can
read off the cutting height currently set in 5 mm steps.
Halting/stopping the robotic lawnmower:
• To stop the robotic lawnmower, press the stop but-
ton (4).
• The robotic lawnmower stops immediately and the
blade disc (6) stops.
m ATTENTION
The robotic lawnmower is not switched off, it has only
been stopped. Always use the "POWER ON/OFF"
button to switch the robotic lawnmower off.
Switching the robotic lawnmower on:
• The robotic lawnmower can then be restarted as
described below.
m NOTE
Before the robotic lawnmower (1) starts mowing, an
acoustic signal (four beeps) is heard, then the blade
disc (6) starts rotating.
• Press the
til the robotic lawnmower (1) switches on.
• For the first use, enter the default PIN code "0000"
by pressing "OK" four times when the number "0"
flashes. (The PIN code can be changed as de-
scribed in point 9.2.1).
• After confirming the fourth digit with the "OK but-
ton", the robotic lawnmower is ready for use. The
word "IdLE" appears on the display.
m NOTE
The robotic lawnmower (1) switches off automatically
after 30 seconds if no input is made.
m ATTENTION
If the PIN code is entered incorrectly 10 times, "LOCK"
appears on the display. The device is now locked for
10 minutes before you can enter the PIN code again.
• Press the "START" button and then the "OK" button
to start mowing.
• If you press the "HOME" button and then the "OK"
button, the robotic lawnmower (1) returns to the
charging station (10) with the mowing function
switched off.
The robotic lawnmower (1) operates continuously un-
til the battery charge is too low. The robotic lawnmow-
er automatically returns to the charging station (10).
The cutter disc is deactivated in this state.
m NOTE
After the battery is fully charged, the robotic lawn-
mower starts again. Alternatively, the robotic lawn-
mower remains in the charging station (10) in accord-
ance with the set mowing schedule.
(By default, the robot mows from Monday to Friday
from 09:00 - 15:00 hrs)
www.scheppach.com
-button ("POWER ON/OFF" button) un-
