MAINTENANCE
The remote control needs no particular maintenance. To ensure optimum performance from the remote
control, once a year check the cables and the electrical connections.
Clean the remote control with a soft cloth dampened with water. Do not use chemical or abrasive products
to clean the remote control.
TECHNICAL DATA
MODEL
OUTPUT CHARACTERISTICS
Current capacity of right or left single thruster
commands.
INPUT CHARACTERISTICS
(1)
Supply voltage
(2)
Current absorption
Maximum current absorption
AMBIENT CHARACTERISTICS
Operating temperature
(4)
Protection rating
GENERAL
Dimensions including frame (L x L)
Weight
(1)
With supply voltage less than 8 Vdc the remote control can reset.
(2)
Typical value with remote control disabled.
(3)
Typical value with remote control enabled and both joysticks activated.
(4)
Excluding the back of the remote control (IP20).
®
QUICK RESERVES THE RIGHT TO MODIFY THE TECHNICAL CHARACTERISTICS OF THE EQUIPMENT AND THE CONTENTS OF THIS MANUAL WITHOUT PRIOR NOTICE.
TCD1044 - REV001B
MAINTENANCE - TECHNICAL DATA
(3)
TCD 1044
4A max
from 8 to 31 Vdc
10 mA
95 mA + absorption of the contactor coil
from -20 to +70 °C
IP 66
78 mm x 131 mm
250 g
