SYSTEM ERRORS AND PROBLEMS
GB
SYSTEM ERRORS
When the remote control is switched on, it may signal the presence of system errors.
Checksum error flash
If the error is detected, all the leds will flash quickly.
®
In this case an assistance point or the Quick customer service must be contacted as soon as pos-
sible.
SYSTEM PROBLEMS
System problems are listed below, divided into two categories:
automatic reset problems and manual reset problems.
AUTOMATIC RESET PROBLEMS
Resetting after problems of this type occurs automatically, as soon as the cause that has generated
the problem disappears.
Low voltage supply
The problem is signalled if the power supply voltage descends below 10.5Vdc for more than one
second. Resetting after this problem occurs if the power supply voltage exceeds the threshold of
11.5Vdc for more than one second. Check the charge state of the battery group that supplies is
derived or the electrical circuit.
In the case of this problem, the enabling leds go off for a moment.
Protection against prolonged motor activity
After activating the single thruster for about 5 minutes continuously, the relevant thruster command
is interrupted.
In this case, both direction leds will flash. Resetting after this problem occurs automatically after a
period of time, calculated by the remote control, necessary to partially cool the thruster.
MANUAL RESET PROBLEMS
Reset problems of this kind occur shut off and turn on the remote control.
Overload on the command electrical line
This problem is signalled when the remote control finds a short circuit or overload on the thruster
command electrical line. In the case of this problem, the leds relative to the command electrical line
on which the anomaly has been detected and the enabling leds flash slowly.
Check the wiring of the electrical lines from the remote control to the thruster and absorption of the
contactors installed on the thruster.
Interruption on the command electrical line
This problem is signalled when the remote control finds an interruption on the thruster command
electrical line. In the case of this problem, the leds relative to the command electrical line on which
the anomaly has been detected and the enabling leds flash fast.
Check the wiring of the electrical lines from the remote control to the thruster.
