Floor & Upholstery Cleaner
•
Detaching: Pull up the handle of the
fresh water tank until the tank is de-
tached from the device. It can then be
lifted out of the compartment.
Attachment
•
Attaching: There are three hooks on
the bottom of the attachment (16).
First plug them into the appropriate
openings on the front of the cleaning
foot. Flip the attachment towards the
cleaning foot and press it down until
you hear it engage in place.
•
Detaching: Reach into the recess be-
neath the cover of the hose connec-
tion (15), pull the attachment up here
and flip it away.
Rotating Brushes – Carpet and Hard
Floor
The two rotating brushes for a carpet (20)
and hard floor (19) are each secured in
the cleaning foot and removed from it in
the same way. For both of them the de-
vice must be placed on the floor so that
the brushes are pointing upwards.
PLEASE NOTE: It is essential that you
first remove the water tanks (10, 12)!
•
Attaching: Place one side of the brush
in the recess provided and press
down firmly on the other side. You
must hear and feel it engage.
•
Detaching: Simply pull up one brush
and then remove it at a slight angle.
Upholstered Furniture Attachment
•
Attaching it to the hose (26): Plug the
upholstered furniture attachment onto
the handle (24) of the hose until you
hear it engage in place.
•
Detaching it from the hose: Release
the end piece of the upholstered
furniture attachment from the locking
lug on the handle. To do this, slide
the end piece forwards, away from the
handle, with your thumb.
01908_Inlay_de-en-fr-nl_A5_V1.indb 17
01908_Inlay_de-en-fr-nl_A5_V1.indb 17
•
Attaching the hose to the cleaning
foot (8): Open up the cover of the
hose connection (15) and plug the
wide end of the hose into the ex-
posed opening.
•
Detaching the hose from the cleaning
foot: Press the release button (25) and
pull out the hose. Flip the cover of the
hose connection shut again.
•
Hang it in the holder (14): Press the
hose handle (24) into the holder.
PARKING POSITION
•
When the body of the device is
placed in a vertical position, it locks
in this position, the device is upright
and does not need to be supported
(parking position).
•
To be able to push the device com-
fortably, release the parking position
as follows: Step on the pedal for
releasing the parking position (6) and
at the same time move the handle (1)
towards you and downwards.
WINDING UP THE CABLE
The connecting cable can be wound
around the upper (3) and lower (5) cable
holders. To do this, turn down the hook
of the lower cable holder.
Turn the hook up to quickly unwind the
connecting cable.
EN
17
