12 Transport (fig. 14)
1. Tighten the locking screw (7) to lock the rotary table
(13).
2. Push the saw head (4) downwards and lock it with the
locking pin (25). The saw is now locked in the lower
position.
3. Carry the product by the transport handle (37).
4. To reassemble the product, proceed as described in
8, 9, 10.
13 Storage
Store the product and its accessories in a dark, dry and
frost-free place that is inaccessible to children.
The optimum storage temperature is between 5°C and
30˚C.
Store the product in its original packaging.
Cover the product to protect it from dust or moisture.
Store the operating manual with the product.
14 Electrical connection
The electrical motor installed is connected and ready
for operation. The connection complies with the ap-
plicable VDE and DIN provisions. The customer's
mains connection as well as the extension cable used
must also comply with these regulations.
14.1 Important information
In the event of overloading, the motor will switch itself off.
After a cool-down period (time varies) the motor can be
switched back on again.
WARNING
The maximum permissible mains impedance Zmax of
the product is 0.323 Ohm. As a user of this product, you
must determine, in consultation with the power supply
company if necessary, that the product is only connect-
ed to a supply whose impedance is less than or equal
to Zmax!
14.2 Special connection conditions
• The product fulfils the requirements of EN 61000-3-11
and is subject to special connection requirements.
This means that use at any freely selectable connec-
tion points is not permitted.
• The product can cause temporary voltage fluctuations
in unfavourable mains conditions.
• The product is intended exclusively for use at connec-
tion points which
a) do not exceed a maximum permitted mains imped-
ance "Z" (Zmax. = 0.323 Ω), or
b) have a continuous current carrying capacity of the
mains of at least 100 A per phase.
• As the user, you are required to ensure that the con-
nection point at which you wish to operate the product
fulfils one of the requirements mentioned, a) or b). If
necessary, consult with your energy supplier in this re-
gard.
32 | GB
14.3 Damaged electrical connection
cables
The insulation on electrical connection cables is often
damaged.
This may have the following causes:
• Pressure points, where connection cables are passed
through windows or doors,
• Kinks where the connection cable has been improper-
ly fastened or routed,
• Places where the connection cables have been cut
due to being driven over,
• Insulation damage due to being ripped out of the wall
socket,
• Cracks due to the insulation ageing.
Such damaged electrical connection cables must not be
used and are life-threatening due to the insulation dam-
age.
Check the electrical connection cables for damage regu-
larly. Ensure that the connection cables are disconnected
from electrical power when checking for damage.
Electrical connection cables must comply with the appli-
cable VDE and DIN provisions. Only use connection ca-
bles with the same designation "H05VV-F".
The printing of the type designation on the connection ca-
ble is mandatory.
Safety information for replacing damaged or defective
mains connection cables
Connection type X
If the mains connection cable of this product is damaged,
it must be replaced by a specially prepared mains con-
nection cable which can be obtained from the manufactur-
er or its service department.
14.4 AC motor
Connections and repair work on the electrical equipment
may only be carried out by electricians.
• The mains voltage must be 220 V - 240V~.
• Extension cables up to 25 m long must have a cross-
section of 1.5 mm².
Please provide the following information in the event
of any enquiries:
• Type of current for the motor
• Motor data - type plate
15 Repair & ordering spare parts
Spare parts and accessories can be obtained from our
Service Centre. To do this, scan the QR code on the front
page.
After repairs or maintenance, make sure that all safety-re-
lated parts are installed and are in perfect condition. All
parts which may cause injury must be kept where they
are inaccessible to children or others.
