Table of contents
1
Introduction ........................................................
2
Product description (Fig. 1-16)...........................
3
Scope of delivery................................................
4
Proper use..........................................................
5
Safety instructions..............................................
6
Technical data....................................................
7
Unpacking ..........................................................
8
Assembly............................................................
9
Commissioning...................................................
10 Operation ...........................................................
11 Maintenance.......................................................
12 Transport (fig. 14)...............................................
13 Storage...............................................................
14 Electrical connection ..........................................
15 Repair & ordering spare parts ............................
16 Disposal and recycling .......................................
17 Troubleshooting .................................................
18 EU Declaration of Conformity.............................
19 Exploded view .................................................... 113
Explanation of the symbols on the
product
Symbols are used in this manual to draw your attention to
potential hazards. The safety symbols and the accompa-
nying explanations must be fully understood. The warn-
ings themselves will not rectify a hazard and cannot re-
place proper accident prevention measures.
Before com-
missioning,
read and ob-
serve the oper-
ating manual
and safety in-
structions!
Wear hearing
protection.
If dust builds
up, wear respi-
ratory protec-
tion!
22 | GB
22
23
23
23
24
27
27
28
28
29
31
32
32
32
32
33
34
34
Protection
class II (double
insulation)
The product
complies with
the applicable
European di-
rectives.
Signal word to
indicate an im-
minently haz-
ardous situa-
DANGER
tion which, if
not avoided,
will result in
death or seri-
ous injury.
www.scheppach.com
Wear safety
goggles.
Attention! Dan-
ger of injury!
Do not reach
into saw blade
while it is run-
ning!
Attention! La-
ser beam
1
Introduction
Manufacturer:
Scheppach GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer
We hope your new product brings you much enjoyment
and success.
Note:
In accordance with the applicable product liability laws,
the manufacturer of this product assumes no liability for
damage to the product or caused by the product arising
from:
• Improper handling
• Non-compliance with the operating manual
• Repairs carried out by third parties, unauthorised spe-
cialists
• Installing and replacing non-original spare parts
• Improper use
• Failures of the electrical system in the event of the
electrical regulations and VDE provisions 0100, DIN
57113 / VDE0113 not being observed.
Signal word to
indicate a po-
tentially haz-
ardous situa-
tion which, if
WARNING
not avoided,
could result in
death or seri-
ous injury.
Signal word to
indicate a po-
tentially haz-
ardous situa-
CAUTION
tion which, if
not avoided,
could result in
minor or mod-
erate injury.
Signal word to
indicate a po-
tentially haz-
ardous situa-
tion which, if
ATTENTION
not avoided,
could result in
product or
property dam-
age.
