8. Remove the hole covers from the left middle side of the appliance and reinsert
them on the right side.
9. Attach the lower door to the bottom hinge carefully and hold the door in
position.
10. Align the middle hinge to the prepared holes on the left side properly and screw
it tightly. Ensure that the lower door is fixed safely and properly by the hinges.
It may be necessary to turn the middle hinge through 180
prepared holes properly (depending on model).
11. Remove the hole covers from the left upper side of the appliance and reinsert
them on the right side (depending on model).
12. Attach the upper door to the middle hinge carefully and hold the door in
position.
13. Align the upper hinge to the prepared holes on the left side properly and screw
it tightly. Ensure that the upper door is fixed safely and properly by the hinges.
It may be necessary to turn the upper hinge through 180
prepared holes properly (depending on model).
14. If the appliance is equipped with an upper hinge cover (depending on model),
reinstall it.
NOTICE! Adjust the door properly. The seal must close properly.
