NOTICE! Adjust the doors properly before you finally tighten the screws
of the hinges. The seals must close properly.
➢ Empty the appliance.
➢ If possible, remove all door trays, glass shelves and drawer from the fridge /
freezer so that they cannot be damaged.
➢ It is necessary to tilt the appliance backwards while removing the doors. You
should rest the appliance on something solid so it will not slip while changing
the hinge positions.
➢ Do not lay the unit flat as this can damage the cooling system.
➢ All parts removed must be saved for proper reinstallation of the doors.
➢ Always remove the doors carefully. Keep the doors in a safe place so that
they cannot be damaged.
1. Unscrew the right upper hinge and remove it.
It may be necessary to remove the cover of the hinge previously (depending
on model).
2. Lift the upper door and remove it carefully.
3. Unscrew the right middle hinge and remove it.
4. Lift the lower door and remove it carefully.
5. Unscrew the right bottom hinge and remove it.
It may be necessary to unscrew the adjustable feet previously (depending on
model).
6. Remove the hole covers from the left bottom side of the appliance and reinsert
them on the right side (depending on model).
7. Align the bottom hinge to the prepared holes on the left side properly and
screw it tightly.
It may be necessary to turn the bottom hinge through 180
prepared holes properly (depending on model).
It may be necessary to unscrew the adjustable feet previously (depending on
model).
P
REPARATORY MEASURES
C
HANGE OF THE HINGE POSITION
53
:
:
0 to align it to the
