Commend TS 8210V I Kurzanleitung

Outdoor touch screen station TS 8210V I
Dimensions
Measuring units in mm (in), not to scale!
139 (5.47)
240 (9.45)
Mounting
Press the front panel onto the mounting box.
Attention:
• Ensure that the microphone faces down and that it is not
covered.
• To avoid overheating, protect the device from direct sunlight.
Recommended mounting height
TS 8210V I
Finished floor Finished floor
Extent of supply
• Intercom station
• Microfibre cleaning cloth
• Snap ferrite
• Disassembling tool
• 2 x Unlocking tool
Disassembly
1
Press both unlock tools into the openings to unlock the Intercom
station.
Insert the disassembling tool in the gap between front panel and
mounting box and take off the front panel.
2
1
1
