CBE PC100 Bedienungsanleitung Seite 16

13
14
15
16
17
1 A 8
18B
19
20
GB
22
16
WASTE WATER TANK
To connect to the waste water tank probe.
MAINS
1) + output heating it depends on the lights switch
on the main general button (PC100).
2) + output water pump - toilet, it depends on the pump switch.
1
4 7
3) + output awning light, it depends on the awning switch.
2 5 8
4-5-6) + output lights group A"
3 6 9
(PC200) or on the main general button (PC100).
7-8-9) + output lights group B"
(PC200) or on the main general button (PC100).
MAINS
1 4 1) + output aux (solar regulator), direct B2.
2-3) + output 3 way function / AES refrigerator
2 5
4) + output electric step (direct B2).
3 6
5-6) + output gas mains' supply (fridge, kitchen, boiler valve).
FRESH WATER TANK
To connect to the
16
9
1 8
SIGNALS
1) + input signal contact key engine starting.
1 2
2) + input signal "S" net coming from the CBE battery charger
SIGNALS (OPTION
1 1) - input "D+" negative signal (-)
2
2) + input signal contact key engine starting.
1) + input signal "S" net coming from the CBE battery charger.
1
2 2) /
MASSES
To connect to the negative pole of the services battery or to the chassis of the
vehicle.
SERVICES BATTERY
To connect to the positive pole of the services battery.
CAR BATTERY
To connect to the positive pole of the car battery.
,
" , it depends on the lights switch
" , it depends on the lights switch
"
fresh water tank probe.
CONTROL PANEL
To connect to the 16 poles connector of the control panel.
(OPTION "A ) "
"B ")
MASSES
To connect to the mains' masses.
(PC200) or
"
