Recommended Placement
Study
Bedroom Bedroom
Garage LivingRoom Kitchen
Basement
How to Install the Detector
A IMPORTANT!
THIS SMOKE DETECTOR IS DESIGNED
A WARNING!
FAILURE TO PROPERLY INSTALL AND
OPERATION OF THE DETECTOR AND
Installation Method
1.Draw a horizontal or vertical line of 4.7 in (12 cm) ength at the intended place of installation on
the ceiling or wal
06
Smoke Detectors
o
CO Carbon Monxide Detectors
co Smoke& CarbonMonoxide Detectors
FireExtinguishers
TO BE MOUNTED ON THE CEILING OR WALL.
ACTIVATE THIS DETECTOR WILL PREVENT
WILL PREVENT ITS SENSITIVITY TO FIRE HAZARDS.
2. Align the two ong mounting slots with the line. Mark the center of each slot
3. Dril holes at the two marks using an appropriate y sized dril bit.
4 Insert the anchor plugs and screw on the mounting bracket with the provided screws. Do not
over-tighten the screws to avoid bending the mounting bracket.
5. Attach the detector to the mounting bracket and turn clockw•se to ock the detector.
6.Test the smoke detector according to the steps in the section below.
Alarm Test
The detector must be properly attached to the base plate before it can be tested.
. Press the central
PROPER
2 The unit beeps 3 times.
3.The red LEDflashes rapid y with an alarm tone signal.
NO E:The test function accurate y tests the detector's smoke sensing circuit without the need of
test smoke. f your smoke detector fai s to give an audible test signal, please refer immediate y to
the troubleshooting guide at the end of this manual.
i
01 02
test button and release the button.
03
