BRAND Liquid Handling Station Gebrauchsanleitung Seite 91

Volume
1 - 50 μl
*not a standard spare part, please contact the manufacturer.
Piston and seal sets
Volume
10 - 200 μl
40 - 1000 μl
1.9.2.2 Liquid End 8-Channel 50 - 300 µl
Packing unit (A) 8 pieces, PU (B) 3 pieces
The appearance and dimensions of the spare parts correspond to the respective nominal volume.
1
2
Ill. 8: Shaft and seal
1 Seal
2 Shaft
Volume
1 - 50 μl
20-300 μl
*incl. 8 gaskets and 1 assembly wrench
Liquid Handling Station 997496
A B*
7096 02 -
A*
7096 30
7096 32
C D
7096 08 7096 12
Order No.
7096 04
7096 06
B
7033 43
7033 46
Devices and components
E
7096 24
Operating manual English
91
