Scope of supply BDT 010-RC

The BDT 010-RC fitting drive and accessories for the BDT are available from
your D+H service and sales partner.
Please order the activPilot Comfort PADM fitting system and the cable
transition from Winkhaus.
20/36
BDT 010-RC
a 1x Fitting drive
b 1x Base plate
c 1x Clamp (6 pole)
d 1x Fixing clip
e 1x Square shaft (7mm x 7mm) l=55mm
f 1x Lock washer
g 2x Countersunk screw M5 x 45 mm
h 1x Countersunk screw 4,1 x 19 mm
e
f
b
c
English
g a
d
h
