6. Installation
1
7
2
9
3
3
4
5
6
7
9
8
4
3
Loosen the three screws (8) on the holding ring
(7) but do not undo them completely.
Use a long slotted-head screwdriver to lever out
the circlip (9) and put it to one side.
WARNING - risk of injury
Wear gloves and protective eyewear
when working on the circlip.
Attach the sink fl ange (3) together with the
rubber seal on top (4) into the sink drain
opening. Ensure you position it in the centre.
Weigh the sink fl ange down with the disposer
from above to make it easier to assemble
everything. If necessary, use an underlay in
the sink to protect the sink from scratching.
Push the lower seal (5), the retaining ring (6)
and the holding ring (7) onto the sink fl ange
from below and press the circlip (9) into the
groove in the sink fl ange (3).
WARNING - risk of injury
Wear gloves and protective eyewear
when working on the circlip.
