7
8
7
11
10
9
11
24
10
15
16
13
II.
I.
12
Connect the outlet elbow pipe (16) to the
outlet opening (13) anti-vibration outlet and
secure it with the hose clamp (15).
Push the disposer (10) against the sink fl ange
(3) from below and turn the tabs of the lower
holding ring (11) loosely over the retaining
ring (7).
Note: The disposer is heavy. Have somebody
else help you to install it on the sink if
necessary.
Use the enclosed hex key (24) as a lever and
tighten the lower holding ring (11) as shown.
You have reached the end position when the
tabs on the lower holding ring (11) slide over
the bumps on the holding ring (7). In doing so,
note the alignment of the outlet opening (13)
for the continued installation process.
Insert the hex key (24) back into the holder
and attach it near the disposer with the
adhesive tape attached on the rear. The key
will be needed in the event of any problems.
Optional (only use if the dishwasher outlet is
to be connected to the disposer):
Insert the dishwasher outlet hose fi rmly
into the dishwasher connection (12). We
recommend securing it with a spring clip.
eng
11
