Modular Linking
A number of fan heaters can be connected
fashion. A total of ten units can be controlled
control panel. The required connections can be made in a daisy chain
fashion as shown in Fig. 9. (References
ECP Electronic Control
Master Unit
SU Slave unit
MLC Modular Linking Cable
CPC Control Panel Cable
To make these connections remove
an appropriate LAN cable (not supplied) to the BUS OUT control socket
('D' in Fig. 9) of the Master Unit. Fix this cable in the back panel using
suitable cabie gland (not supplied). Continue this process for ail linked
heaters. Replace the control housing of each heater and power up all
units. Ensure that ail control settings function correctly.
Thermal Safety Cut-out
The power supply to the heating elements will be interrupted if one or a
combination Of the foflowing abnormal events occurs:
1. Air inlet or outlet grilles are obstructed.
Internal ventilation is impaired due to build up of dust and fluff.
2.
3 Blower unit stalls.
Note: Before re•setting the cut-out, the reason for activation must be
determined and corrective action
To reset the thermal safety cut-out, access reset button as shown in
Fig. 6 and push in direction of arrow.
Cleaning
WARNING: DISCONN ECT SUPPLY before carrying out maintenance.
External appearance can be maintained by wiping occasionally with a
damp cloth. For stain removal, a weak soap solution can be applied with
a cloth and the surface wiped dry. Care must be taken to avoid any
moisture ingress into the product.
After Sales Service
Should you require after sales service or should you need to purchase
any spares, please contact the retailer from whom the appliance was
purchased or contact the service number reEevantto your country on
the warranty card.
Please do not return a faulty product to us in the first instance as this
may result in loss or damage and delay in providing you with a satisfactory
service.
Please retain your receipt
together in a 'daisy chain'
from a single electronic
shown below).
Panel
one of the small knock-outs
taken.
as proof of purchase.
-2
and feed
