II. EQUIPMENT AND ACCESSORIES
A – vacuum cleaner (Fig. 1, 2, 4)
A1 – ON/OFF (
A2 – power cord winding button
A3 – suction vent
A4 – handle
A5 – depression for attachment of accessories
A6 – power cord
A7 – rear wheels
A8 – exhaust grid
A9 – output HEPA filter
A10 – foam micro–filter
B – dust container (Fig. 3)
B1 – holder + container lock
B2 – lid
B3 – bottom lock button
B4 – bottom flap
B5 – textile micro-filter
B6 – foam micro–filter
B7 – separator
B8 – seal
B9 – separator cover
III. VACUUM CLEANER PREPARATION
Remove all packing material, take out the vacuum cleaner and the accessories.
Remove all possible adhesion foils, stick-on labels or paper from the appliance.
VACUUM CLEANER ASSEMBLY
When assembling the vacuum cleaner, follow the procedure indicated in Fig. 1.
Choose appropriate accessories as required (C1 - C4) (Fig. 5). The telescopic suction tube
C7 can be set to an optimum length to suit the user´s height.
IV. USE OF VACUUM CLEANER (Fig. 5)
Before use, unwind (by pulling) the power cable A6 from the vacuum cleaner to a required
length and plug the vacuum cleaner to the mains.
CONTROL
A1 button
A2 button
V. REMOVING THE DUST CONTAINER AND FILTERS
DUST CONTAINER REMOVAL
When taking out the dust container B follow the procedure indicated in Fig. 3. Dispose of
dirt contained in the dust container with regular household waste. An emptied and cleaned
container is to be put back into the vacuum cleaner in reverse order.
) button
- vacuum cleaner ON/OFF switch
- when pressed and held, the unwound part of the power cable
rewinds back inside
C – accessories (Fig. 1)
C1 – floor nozzle
C2 – upholstery nozzle
C3 – brush
C4 – crevice nozzle
C5 – suction hose
C6 – mechanical suction power regulator
C7 – suction tube
C8 – telescopic suction tube locking
