4 RE-ADJUSTMENT OF END LIMITS
4.1. Re-adjustment of down end limit: In case of an automatic adjustment (with rigid link) the re-adjustment
will also be automatic (every 60 cycles). In this case, do not proceed to the following operations.
2
1
>>
1. Position the motor on the down end limit set in §2.5 using the ▼ key.
2. Press the ▼ key 6 times, each time for 6 seconds. After the 2nd, 3rd, 4th, 5th, and 6th press the motor
rotates briefly one way, then in the other*.
3. Position the motor on the new desired lower position using the ▲ and ▼ keys.
4. To confirm the new End Limit position, press ▲ twice, once for 0,5 second without the motor rotating and the
second time for at least 3 seconds, so the motor rotates briefly one way, then in the other*.
4.2. Re-adjustment of up end limit: In case of an automatic adjustment (with buttom slat stopper) the re-
adjustment will also be automatic (every 60 cycles). In this case, do not proceed to the following operations.
1 2
>>
1. Position the motor on the up end limit set in §2.6 using the ▲ key.
2. Press the ▲ key 6 times, each time for 6 seconds. After the 2nd, 3rd, 4th, 5th, and 6th press the motor
rotates briefly one way, then the other*.
3. Position the motor on the new desired high position using the ▲ and ▼ keys.
4. To confirm the new End Limit position, press ▼ twice, once for 0,5 s without the motor rotation and the
second time for at least 3 seconds, so the motor rotates briefly one way and then in the other*.
* Press the buttons until the motor turns into the two directions.
5 CANCELLING THE END LIMITS ADJUSTMENT
- Connect the motor to the settings switch (§2.1)
- Press the ▲ / ▼ keys simultaneously, for at least 7 seconds. The motor rotates
one way, then in the other*, then a few seconds later rotates in both directions*.
After this operation, the motor returns to its factory settings; repeat the operations
from chapter 2.
* Press the buttons until the motor turns into the two directions.
6 OPERATION AND MAINTENANCE
- This drive is maintenance-free.
- Press the ▲ button on the control point to raise the motorised product.
- Press the ▼ button on the control point to lower the motorised product.
Tips and recommendations for use:
PROBLEMS
The motorised product does not operate.
If the motorised product still does not work, contact a drive and home automation professional.
We care about our environment. Do not dispose of the appliance with usual household waste. Give it to
an approved collection point for recycling.
SIMU SAS, F-70100 ARC-LÈS-GRAY as manufacturer hereby declares that the drive covered by these instructions when marked for input
voltage 230V~50Hz and used as intended according to these instructions, is in compliance with the essential requirements of the applicable
European Directives and in particular of the Machinery Directive 2006/42/EC and EMC Directive 2014/30/EU. The full text of the EU declaration
of conformity is available at www.simu.com. Bruno STRAGLIATI, Chief Executive, ARC-LÈS-GRAY, 12/2020.
EN
4/4
>>
>> >>
>>
>>
>>
POSSIBLES CAUSES
The overheating protection on the drive has
been activated.
3
>>
>>
3
>>
>>
4
6s max.
0,5s >3s
4
+
6s max.
0,5s >3s
≥7s
>> >>
2s
7s
SOLUTIONS
Wait for the drive to cool down.
