SPICE
Specifications
Synthesizer Architecture
Number of voices
Monophonic
Type
Analog
Oscillators
2 VCO
VCF
LPF 24 dB/octave
Envelopes
2 AD
Connectivity
Power switch
Push button on/off
MIDI In
5-pin DIN / 16 channels
USB (MIDI)
USB Micro
Headphones
3.5 mm TRS, stereo, 5 mW 32Ω
USB
Type
Class compliant USB Micro
Supported operating
Windows 7 or higher
systems
Mac OS X 10.10 or higher
Oscillator Section
VCO 1 Frequency
VCO 1 Sub 1 Frequency
VCO 1 Sub 2 Frequency
VCO 1 Level
VCO 1 Sub 1 Level
VCO 1 Sub 2 Level
Controls
VCO 2 Frequency
VCO 2 Sub 1 Frequency
VCO 2 Sub 2 Frequency
VCO 2 Level
VCO 2 Sub 1 Level
VCO 2 Sub 2 Level
Seq 1 Assign Osc 1, Sub 1, Sub 2
Buttons
Seq 2 Assign Osc 2, Sub 1, Sub 2
VCO 1Waveform select
Switches
VCO 2 Waveform select
Analog Filter Section
Cutoff
Controls
Resonance
Envelope Section
VCA EG Attack
VCA EG Decay
VCA EG Volume
Controls
VCF EG Attack
VCF EG Decay
VCF EG Amount
Sequencer Section
Capacity
2 sequencers, 4 steps each, assignable clock division
Tempo
Sequence 1 x 4
Control
Sequence 2 x 4
Division x 4
Reset, EG, Next
Play/Stop, Trigger
Buttons
Sequence Octave
Quantize
Division assign x 8
Patch Panel
16 x 3.5 mm TS jack, DC coupled, normalled
Inputs
VCO 1 CV, VCO 1 Sub CV, VCO 1 PWM, VCA CV, VCO 2 CV, VCO 2 Sub CV, VCO2 PWM, VCF Cutoff CV
Play, Reset, Trigger, Rhythm 1 CV, Rhythm 2 CV, Rhythm 3 CV, Rhythm 4 CV, Clock
16 x 3.5 mm TS jack, DC coupled, normalled
Outputs
VCA, VCO 1, VCO 1 Sub 1, VCO 1 Sub 2, VCA EG, VCO 2, VCO 2 Sub 1, VCO 2 Sub 2
VCF EG, Seq 1, Seq 1 Clock, Seq 2, Seq 2 Clock, Clock, Trigger, Phones
Power Requirements
Mains connector
12 V DC, 1000 mA consumption
Physical
Standard operating
5°C – 45°C (41°F – 113°F)
temperature range
Dimensions (H x W x D)
45 x 164 x 321 mm (3.30 x 6.46 x 12.64")
Weight
1.48 kg (3.26 lbs)
