1. Scope of supply

1.1

Included in the scope of supply

Crossbar
Bag with bolts, nuts and washers
1.2

Not included in the scope of supply

DN 160 pipe with socket,
length L
Socket plug DN 160
1. Scope of supply
Pipe clamp DN 160
Size
Carat S
Pipe length L 1610 mm 1820 mm 2000 mm 2340 mm
Hole height B 175 mm
A hole mm should be drilled in the pipe at height B, using a
core drill.
8 / 32
3 PE 5 PE
Carat S
2700 3750
175 mm
Cover
7 PE 9 PE
Carat S Carat S
4800 6500
175 mm 175 mm
