Explosionszeichnung
Version für Stahlseil
material no. quan�ty
1
1
4
2
3
1
1
4
1
5
1
6
1
7
8
1
9
1
10
2
1
11
1
12
13
1
14
1
15
1
16
1
17
1
18
1
TX4500 Winde - Teileliste
item
motor
Socket head screw
powder ink bearing
The eccentric sleev
spring brake
transmission sha�
The clinker set
brake block
Drum
Suppor�ng sha�
powder ink bearing
Gear bracket
The spline sha�
Outside cylinder
The first set of star gear
gasket
The second set of star gear
The third set of star gear
material no. quan�ty
1
19
1
20
1
21
22
2
23
1
24
3
25
1
1
26
27
2
28
1
1
29
30
1
31
1
4
32
33
4
4
34
4
35
36
1
17
item
The clinker cocks
Trigeminal piece
sit of Trigeminal piece
The o-rings
The back cover
Socket head screw
handle
Switching line
power line
red strap
roller fairlead
steel rope
hook
square nut
Flat mat
Spring washers
Outside the hexagonal screw
solenoid
