7.3 Teileliste: Taurus MS3 Latzug (TF-HR-LR01)
Nr. Bezeichnung (ENG)
1 Weight Base Tube
2 Safety Stop Frame
3 Sliding Sleeve
4 Sliding Weight Post
5 Dia33-25mm Sleeve
6 Olympic Spring Clip
7 Weight Holder
8 Guide Rod
9 60x60 Inner Cap
10 50x50 Inner Cap
11 Middle Upper Frame
12 Front Upright
13 Foot Tube
14 Dia48 mm Inner Cap
15 Bracket
16 Pulley
17 F60x60mm Outer Cap
18 Lat Bar
19 Clip
20 Chain
21 Long Chain
22 Low Row Bar
23 Low Bar Grip
24 Lat Bar Hook
25 Weight Carriage Axle
26 Pulley Bushing
27 Upper Cable
28 Lower Cable
29 Ball
30 Protective sleeve
31 Core
Anz.
1
2
2
1
4
2
2
2
1
2
2
1
1
4
2
7
2
1
6
2
1
1
4
1
1
10
1
1
2
2
2
