Setup
Installation Options
w
Rough-in Pan (optional)
Wiring the Loudspeaker
Wire Gauge
The DesignMax DM6C loudspeaker is designed to work with 18 AWG (0.8 mm
Connection Diagrams
Expose six millimeters (1/4 inch)
of bare wire to attach to the
terminals.
Loudspeaker Settings
4 • English
Conduit Fitting
If using a flexible metal conduit, use with a 3/8-inch conduit
fitting or a 3/8-inch dual (duplex) connector.
Note: Conduit fittings are not provided.
3/8-inch single in
) to 14 AWG (2.1 mm
2
70V/100V
2.5W 5W
5W 10W
* Factory default
Transformer Tap Setting
Set tap by turning. Use a flat head screwdriver.
BoseProfessional.com
3/8-inch duplex in/loop
) size wire only.
2
8Ω
70V
10W 20W 40W
20W 40W 80W
100V
** NC: No Connection (do not use)
DesignMax DM6C • Installation Guide
80W*
8Ώ
NC**
