Install Hydraulically
CAUTION!
Danger from dosing medium
splashing around
Improper installation may cause
dosing medium to leak.
Always wear safety equipment
„
like glasses, gloves and chemi-
cal overall when working on the
hydraulic.
1
2
3
4
5
6
7
Version plastic
1
Hose*
2 Union nut
3 Clamping ring
4 Tube nozzle
5 O-ring or flat seal
6 Discharge valve
7 Suction valve
* On the pressure side use a use a
pressure-resistant hose.
For detailed information on
valve variations, please refer
to the operating instructions.
