Install Hydraulically
CAUTION!
Danger from dosing medium
splashing around
Improperly installed hose lines can
come loose.
Only use PTFE hose lines or
„
stainless steel pipes.
When using PTFE, insert a
„
stainless steel support sleeve
into the hose assembly.
Always wear safety equipment
„
like glasses, gloves and chemi-
cal overall when working on the
hydraulic.
EN 10
1
2
3
4
5
6
7
Version stainless steel
1
Pipe/hose
2 Union nut
3 Rear clamp ring
4 Front clamp ring
5 Tube nozzle
(only with hose)
6 Discharge valve
7 Suction valve
For detailed information on
valve variations, please refer
to the operating instructions.
