Terminal Function, information
X403: CU2 / CUVC / CUVP
1 Reference potential
2 Pulse track A
3 Pulse track B
4 Position track (not evaluated)
5 Tachometer monitoring track
6 15 V supply / 24 V supply
X404: External 24 V power supply
1 Reference potential (M24 ext.)
2 Power supply voltage (P24 ext.)
3 Reference potential, tachometer
(M24 SV T)
4 Tachometer supply (P24 SV T)
X405: TTL output
1 Reference potential
2 Pulse track A
3 Inverted pulse track A
4 Pulse track B
5 Inverted pulse track B
6 Position track
7 Inverted position track
8 5 V power supply
X80 Grounding point / screen ground
X81 Grounding point / screen ground
Table 3-2 Terminals
1)
only with 6SE7090-0XX84-3DB1
Digital tacho-Interface
Installation, Connecting-up
Cable cross-section
[mm
1)
or TSY
0,5 to 1,5
0,5 to 1,5
0,5 to 1,5
0,5 to 1,5
0,5 to 1,5
1)
0,5 to 1,5
0,5 to 2,5
0,5 to 2,5
0,5 to 2,5
0,5 to 2,5
0,5 to 1,5
0,5 to 1,5
0,5 to 1,5
0,5 to 1,5
0,5 to 1,5
0,5 to 1,5
0,5 to 1,5
0,5 to 1,5
With cable lug for M4
bolt
With cable lug for M4
bolt
2
] AWG
20 to 16
20 to 16
20 to 16
20 to 16
20 to 16
20 to 16
20 to 14
20 to 14
20 to 14
20 to 14
20 to 16
20 to 16
20 to 16
20 to 16
20 to 16
20 to 16
20 to 16
20 to 16
