Transducer nominal temperature upper limit: Upper nominal (rated) temperature of the
transducer.
Transducer nominal temperature lower limit: Lower nominal (rated) temperature of the
transducer.
Transducer operational temperature upper limit: Upper limit temperature of the trans­
ducer.
Transducer operational temperature lower limit: Lower limit temperature of the trans­
ducer.
Index Sub­
(hex) index
(hex)
0x0056 0x00
0x0058 0x00
0x005E 0x00
0x005F 0x00
0x0203 0x00
0x0055 0x00
0x0056 0x00
0x0057 0x00
0x0058 0x00
52
Authoriza­ Data type
tion
ReadOnly Float32T
ReadOnly Float32T
ReadOnly Float32T
ReadOnly Float32T
Read/ UInteger8T
Write
ReadOnly Float32T
ReadOnly Float32T
ReadOnly Float32T
ReadOnly Float32T
Data Name
size
(bytes)
4 Mainboard
temperature
4
4 Processor
temperature
4
1 Nominal
Tempera­
ture Over­
load
Warning
4 Transducer
temperature
4
4
4
Description
Upper limit
Lower limit
Upper limit
Lower limit
Enables/
disables warn­
ings when the
temperature
exceeds/falls
below the
nominal (rated)
temperature of
the sensor
0x00 = Disable
0x01 = Enable
Nominal (rated)
temperature
upper limit
Nominal (rated)
temperature
lower limit
Operating
temperature
upper limit
Operating
temperature
lower limit
ELECTRICAL CONNECTION
U9C
