Traveling With The Sharpener - SPARX SHARPENER 3 Bedienungsanleitung

Pull up on the Air Filter Pull-Tab to lift the filter out of the
sharpener.
5
INSERT THE NEW AIR FILTER
Vacuum any remaining dust from the Filter Housing area.
Insert the new Air Filter with the pull-tab on the left-hand side
and black seal going into the sharpener. Once inserted, pivot
the Filter Clamps into their original positions.
6
RESET THE AIR FILTER BUTTON
Once your filter has been replaced, hold down the
Button for two seconds until an audible tone is heard to reset
the system and extinguish the
TRAVELING WITH THE
SHARPENER
To watch the How-To video, visit
1
EMPTY THE SHARPENER BASE
Lift the Head Unit and wipe the Sharpener Base. To empty
Sharpener Base—wipe completely clean with a damp cloth
(water).
Do not use any solvents or cleaning chemicals in and
around the Skate Sharpener.
2
VACUUM SHARPENER
Without removing the Air Filter, vacuum the top of and around
the Air Filter Housing. We recommend using a HEPA certified
vacuum.
3
INSTALL THE TRAVEL GUARD
Skate Clamp
Open the by pressing and holding down the
Clamp Lever. Install the Travel Guard
the Travel Guard behind the
Air Filter
Air Filter Button.
sparxhockey.com/howto
by placing the claw of
Grinding Ring Arbor's impeller as
shown below. Release the Clamp
middle section of the Travel Guard
the Skate Clamp.
4
REMOVE THE CLAMP LEVER
Slide the Clamp Lever (A) off of the
A
5
TRAVEL WITH THE SPARX TRAVEL CASE
For the highest level of protection and safety when
traveling with your Sparx Skate Sharpener and accessories,
we recommend using the Sparx Travel Case (sold
separately).
When setting up the Sparx Sharpener after travel, wipe
down the Grinding Ring Arbor's face and threaded arbor
to remove any unwanted steel shavings that may have
gathered during transit. This will ensure a proper fit
between the Grinding Ring Arbor and the Grinding Ring.
MAINTENANCE
Lever. Ensure that the
is held securely in
Lever Dock.
25
