SPARX SHARPENER 3 Bedienungsanleitung Seite 24

fIGURE SKATES
To watch the How-To video, visit
* Figure Skate Adapters are sold separately.
Before loading a figure skate,
installed onto each end of the skate steel as shown below.
1
PLACE ADAPTER OVER TAIL AND TOE PICK
Using the included wrench tighten the set screw until finger tight
do not over tighten, the adapter should still be able to pivot.
Be sure to keep the drag pick covered. After both adapters are
installed perform a visual to check to ensure that both adapters
are on a level horizontal plane.
OPERATION
20
sparxhockey.com/howto
Figure Skate Adapters must be
2
ADJUST THE GRINDING RING HEIGHT
Set the grinding ring height setting to Figure (1). Look for the
contact point at which the grinding ring starts to roll on the skate
using the move button. If the contact point is leaving some of
the skate blade untouched you may need to adjust the adapter
slightly higher.
3
INSERT SKATE INTO SKATE CLAMP
We recommend having the toe pointing right. Ensure that the
adapters are sitting flush with the top surface of the sharpener.
4
CONTINUE THE SHARPENING PROCESS
Refer to "Sharpening Skates" in the Operation section
of the manual.
